0.0 Executive Summary

This report shows the setup and testing of multi-factor authentication (MFA) for SSH on an Ubuntu Linux system.

The goal was to make remote logins more secure by requiring two login steps:

  • an SSH key

  • a 6-digit TOTP code

Normal password logins were disabled.

The setup used OpenSSH and PAM to control login access and reduce the risk of brute-force attacks and unauthorized access.

Testing confirmed that users needed both a valid SSH key and a valid TOTP code before the system allowed access.

1.0 SSH Hardening with Multi-Factor Authentication

1.1 Project Description

The goal of this task was to build Linux hardening and SSH security skills using OpenSSH and PAM.

The setup included:

  • Installing the Google Authenticator PAM module (libpam-google-authenticator)

  • Requiring SSH public key authentication

  • Requiring TOTP verification codes

  • Restricting SSH access to approved users

  • Testing login security with different login scenarios

This setup improves SSH security by requiring two separate login factors before access is granted.

1.2 Technical Task / Troubleshooting Process

The process focused on improving SSH login security and testing the new settings.

Key Actions & Observations

  • Checked that the Google Authenticator package was not already installed.

  • The libpam-google-authenticator package was installed on the Ubuntu Server.

  • Ran the MFA setup wizard under the standard user account (eldon).

  • Enabled single-use TOTP codes and basic rate limiting.

  • Modified /etc/pam.d/sshd to load the pam_google_authenticator.so module.

  • Disabled normal password prompts inside the SSH PAM configuration.

  • Updated /etc/ssh/sshd_config with the following settings

    • UsePAM yes

    • KbdInteractiveAuthentication yes

    • AuthenticationMethods publickey,keyboard-interactive

  • Restricted SSH access using:

    • AllowUsers eldon

  • The SSH service was restarted to apply the new settings.

  • Verified the SSH configuration using the built-in test commands.

Root Cause: Default SSH settings allowed single-factor logins using standard passwords. This increases the risk of unauthorized access. This issue was resolved by enabling PAM-based MFA.

1.3 Resolution and Validation

SSH and PAM settings were tested through login attempts and configuration checks.

Parameter Configuration Value
Authentication System OpenSSH / PAM
Login Method SSH Key + TOTP
Password Login Disabled
Rate Limit 3 Attempts per 30 Seconds
Token Protection Single-Use TOTP
Scope Remote SSH Access

Validation Steps

  1. Verified that password prompts no longer appeared during SSH login attempts.

  2. It was confirmed that valid SSH keys were required before the MFA prompt appeared.

  3. Tested invalid SSH keys and confirmed that access had been denied.

  4. Attempted direct root SSH access and confirmed that the connection was blocked.

  5. It was verified that disabling public key authentication prevented access to the MFA prompt.

2.0: CONCLUSION

2.1 Key Takeaways

  • SSH MFA requires changes to both the SSH service and PAM configuration files.

  • SSH keys combined with TOTP codes improve the security of remote logins.

  • MFA testing should be performed using standard user accounts instead of root sessions.

  • The correct system time is important for TOTP authentication to function properly.

2.2 Security Implications & Recommendations

Risk: Single-Factor SSH Login

Using only passwords or SSH keys increases the risk of unauthorized access if the credentials are stolen.

Mitigation: Require MFA for all remote SSH logins.

Risk: Unauthorized SSH Access

Open SSH access increases the exposure to brute-force attacks and login abuse.

Mitigation: Restrict SSH access to approved users and disable direct root logins.

Best Practices

  • Backup SSH and PAM files before making changes

  • Keep an active SSH session open during testing

  • Test SSH settings using commands like sshd -T

  • Review SSH logs for suspicious login attempts

Framework Alignment

  • Supports NIST SP 800-53 access control requirements

  • Aligns with CIS Linux Benchmark recommendations

  • Supports ISO 27001 access control guidance
